Description
Specifications
1. Maximum PV open circuit voltage
150V (at the lowest temperature)
138V (at a standard temperature of 25º)
2. Minimum PV voltage
60V/80V
3. Rated Charge Current
60A
80A
100A
4. Maximum input power
12V
780W
1040W
1300W
24V
1560W
2080W
2600W
36V
2340W
3120W
3900W
48V
3120W
4160W
5200W
5. Output – Self-consume <35mA(48V)
6. MPPT highest accuracy – 99%
7. Maximum charging efficiency – 97%
8.Charging control mode – Multi-stage MPPT, Absorption, Float, Equalization, CV)
9. Float charge – 41.4V/55.2V
10. Boost charge – 43.2V/57.6V
11. Equalization charge – 43.8V/58.4V
12. Battery Type
GEL, SLD, FLD and USR(default), Lithium batteries customization series 3.7V,4 series
3.7V,4 series 3.2V,5 series 3.2V
13. Other
● Human interface – Color LCD with backlight, 3 buttons
● Cooling mode – Iron case heat sink and cooling fan
● Wiring – High current copper terminal≤25 mm* (3AWG)
● Temperature probe – 10K, line length 3 meters
● Communication mode – RS485, RJ45 port
● Working temperature range – -20~+55° C
● Storage temperature range – -30~+80° C
● Humidity – 10%~90% No condensation
